L-15
Sanway
powered passive
Overview
L-15 is a coaxial bi-amp passive speaker, mainly designed for different touring performances, as well as various fixed installations. L-15 is suited for use as front stage monitor, live band feedback, and main speaker for small live shows. The enclosure consists of a 15″ neodymium woofer and a 3inch compression driver. 18mm palywood was painted by dutable and weatherized exterior finish.
Key Features
High Power HF without a Compression Driver
Full range stand alone enclosure(65Hz to 15Hz)
New technology
Controlled dispersion(50 by 25)
Bi-amped or passive
Minimal size and weight
Powered version mouted D1-650D plate amplifier with DSP
Description
1>. 15" Coaxial Sound System Speaker
2>. Compact High-efficiency Neodymium Speaker System
3>. Nightclub Coaxial Audio Speaker
Specifications
Frequency Response (±3 dB) | 50 Hz - 20 KHz |
Sensitivity (1w/1m) | 106 dB |
Long-term SPL | 133 dB |
Maximum SPL | 139 dB |
Nominal Impedance | 8 ohms |
Power rated | 450 watts |
Peak Power handling | 900 watts |
Nominal Dispersion | 50°Axi-symmetric |
Dimensions (H x W x D) | 365 mm x 580 mm x 440 mm |
Enclosure Material | 18mm plywood |
Surface Finished | Grey or White color selectable |
Grille | 1.5mm black perforated steel framed mounted grey or white color acoustic foam |
Net weight | 28kg |
Low Frequency Driver | 1×15 inch Neodymium woofer |
High Frequency Driver | 1×3 inch Neodymium compression driver |
Input Connectors | Neutrik NL4 X 2 |
